》》》規格表：
|
model |
HOC-JH216 |
HOC-JH210 |
HOC-JH315 |
HOC-JH480 |
HOC-JH210T |
HOC-JH315T |
||||
|
Interior W/D/Hmm |
600/600/600 |
700/500/600 |
700/500/900 |
800/600/100 |
700/500/600 |
700/500/900 |
||||
|
Operate Space W/D/Hmm |
600/500/600 |
600/500/600 |
600/500/900 |
800/500/1000 |
600/500/600 |
600/500/900 |
||||
|
Exterior W/D/Hmm |
1140/1385/2175 |
950/1240/1510 |
950/1240/1810 |
1290/555/1000 |
600/500/600 |
600/500/900 |
||||
|
Power |
200V 3 |
200V 3 |
200V 3 |
200V3 |
200V3 |
200V3 |
||||
|
Temp.Range |
+60℃~300℃ Max |
+60℃~200℃ Max(Option 300℃ Max) |
||||||||
|
Temp.Controller |
Digital Display & Automatic PID Control±0.5% |
|||||||||
|
Control System |
Input:CA Sensor Output:SSR |
|||||||||
|
Temp.Uniformity |
200℃±2℃/300℃±4℃(No-load) |
200℃±3℃(No-load) |
||||||||
|
Rise Time |
Ambient Temp. to 200℃ Approx 40 Min.((No-load) |
|||||||||
|
Inlet (N2/Clean air) |
|
|
|
由后往前送風 |
||||||
|
Outlet |
|
|||||||||
|
Materials |
■Interior:Stainless Steel ■Exterior:Steel with Baked Enamel ■Rockwool Insulation |
|||||||||
|
Heater |
Sheathed Heater |
|||||||||
|
Clean Level |
Class # 10 or Class # 100 |
|||||||||
|
Safety Device |
■ Leakage Circuit Breaker ■ Over Temperature Protection ■ For Heater Overload ■ Buzzer ■ Phase Reverse ■ For Motor Overload |
|||||||||
|
Standard parts |
■HEPA Filter ■Differential Pressure Gauge ■Timer ■Automatic Adjustable Damper N2 Flow Meter |
|||||||||
|
Option |
■Temp.Recorder ■Programmable Temp.Controller ■Stainless Steel Perforated Tray ■Electronmagnetic Door Lock ■Cooling Device ■ Hocheck Acquisition+Monitory System(Industry 4.0) |
|||||||||
|
Structure (控制箱位于機臺上方） |
Double door |
Single door |
Double door |
|||||||
Due to HOCHECK continuing efforts to improve thrir systms,these spcifications are subject to chenge withoutnotice.
因應長期研發需要，本公司保有規格修改之權利，恕不另行通知.
